Energy from Waste Power Plant
Aberdeen,
Great Britain
The task
The councils of Aberdeen City, Aberdeenshire and Moray are constructing an energy from waste plant at the Aberdeen location, in the North-East of Scotland. ACCIONA will be responsible for the design and turnkey construction, commissioning and the O&M of the plant for a 20 year period. Standardkessel Baumgarte’s (SBG) scope of supply comprises designing and supply of the boiler plant, including the firing system and the flue gas cleaning system.
The solution
The plant comprises a line for the thermal recycling of household waste. The core component supplied by SBG essentially consists of an air-cooled grate furnace and a steam generator for generating superheated steam with three vertical radiation passes, a horizontal convection pass and a vertical economiser. A selective non-catalytic denitrification plant (SNCR) and a quasi-dry flue gas cleaning plant with bag filter are used to clean the exhaust gases.
For more information, please see our reference sheet.
Fuel
Domestic refuse
Number of Lines
1
Heating Value
7.5
.J/kg minimal
9.3
MJ/kg nominal
13.0
MJ/kg maximal
Fuel Throughput
19
t/h nominal
Rated Thermal Input
49.1
MW
Steam Capacity
63
t/h
Steam Temperature
425
°C
Steam Pressure
64
bar
Exhaust-Gas Temperature
145
°C minimal
160
°C maximal
Feed Water Temperature
130
°C
Flue Gas Flow
103,000
Nm³/h nominal
Emission Limit Value
IED
Commissioning
2021
